92500150 HU5 Wilo Pump Mechanical Seal 19.05mm 25.4mm For Circ
Master
Mechanical Seal 92500150 E 1/2 5/8 3/4 1 Pump Seal Mechanical Seal
Basic Info.
Specification
10cm*10cm*10cm
Replacement pump seal for Circ-Master, Flo-Master, XP, XP2, XP2e
and XP3 HP/CP hot tub pumps.
This seal fits the following pump models:
| Circ-Master / Hush pump side discharge (HP) models and the centre
discharge (CP) models. |
| Flo-Master series side discharge and centre discharge models. |
| Aqua-Flo XP2, all models |
| Aqua-Flo XP2e, all models |
| Aqua-Flo XP3, all models |
| Aqua-Flo by Gecko part #: 92500150 |
| Standard seal suitable for pumps used in standard Bromine/Chlorine
environments |
Model | d1(inches) | d7 | d3 | d6 | d2 | l | l3 |
BGM E-5/16 " | 7.925
9.520
12.700
15.875
15.875
15.875
19.050
19.050
25.400
28.575 | 25.4 | 27 | 16 | 20.63 | 24.6 | 8 |
BGM E-3/8" | 22.225 | 23.8 | 14.3 | 17.42 | 22.22 | 6.2 |
BGM E-1/2"
BGM E-5/8" | 25.4 | 26.97 | 17.45 | 20.63 | 22.8 | 6.2 |
30.1 | 30.94 | 20.63 | 23.8 | 26.5 | 8.7 |
BGM E-5/8"H | 31.75 | 30.94 | 20.63 | 23.8 | 30 | 10.3 |
BGM E-5/8 "K | 31.75 | 30.94 | 20.63 | 23.8 | 28.5 | 10.3 |
BGME-3/4"H | 34.925 | 34.11 | 23.8 | 26.87 | 30 | 10.3 |
BGM E-3/4"c | 34.925 | 34.11 | 23.8 | 26.87 | 28.5 | 10.3 |
BGM E-1" | 41.275 | 42.85 | 30.15 | 33.33 | 31.73 | 11.1 |
BGM E-11/8 " | 44.45 | 46 | 33.5 | 36.5 | 31.75 | 11.1 |
We are a manufacturer. All seals have bulk inventory and can be
shipped to you quickly. We promise to ship you in small quantities
within 3 days.Advanced technology, excellence, replace original
1. Different models of mechanicals seals for a wide variety of
Grundfos® pumps, among them: CR(N), NB, NK, CLM, LP, TP, etc.
Available in diverse combinations of materials and different
diameters: 12, 16, 22, 28, 33, etc. Also mechanical seals for
Sarlin®. Division of waster pumps. Available in various materials:
silicon-graphite carbide, silicon carbide-silicon carbide; combined
with EPDM and FKM elastomers.
2. Mechanical seals for EMU® pumps. They get two static faces and
one rotating face. We can supply the complete seal or spare faces.
3. Different designs of mechanical seals for Ebara® pumps, single
and double seals in combinations carbide-silicon carbide and
graphite-aluminium oxide.
4. Mechanical seals for all types of Calpeda® pumps: centrifugal
pumps, multistage, submersible. Different models of mechanical
seals in a wide range of materials.
5. Mechanical seals compatible for APV® pumps, among them: Puma,
ZMA, ZMB, ZMD, ZMS, ZMH, ZMK. Rosista® and Pasilac®, W and W+. Some
designs with wave spring like the special seals for APV Howard®
pumps and Crepaco Clean Line®. All of them have been manufactured
in materials suitable for working with fluids such as juices, milk
and drinks in general.
6. Allweiler, Simple design of mechanical seals simple but with
special measures for this type of pump.
7. Different models of mechanical seals compatible for Alfa-Laval®
pumps series CM, FM, MR, LKH,GM and ALC. Also the models for the
range of lobular SSP and SR pumps. Mechanical seals in different
combination of materials tungsten carbide, silicon carbide,
graphite; combined with different types of elastomers: NBR, EPDM
and FKM.
8. Mechanical seals for ABS® submergible pumps specific wastewater
treatment. Different models of mechanical seal available: oil
chamber mechanical seal and water mechanical seal.
Fixing and Applying Directions of Mechanical Seals
| 1. Select Appropriate mechanical seal to match the materials
according to work conditions and host machine equipment. |
| 2. The radial acting deviation for the shaft(shaft sleeve) of the
installed mechanical seal shall be 0.04mm by maximum while the
axial movement value of the rotor shall be no more than 0.1mm. |
| 3. The seal cover (or shaft cover) of the stationary ring of the
installed mechanical seals,the vertical degree of the seal face
should be 0.04mm by maximum. |
| 5. When conveying medium of over high or low temperature,with
medium which are easy catch fire,easy for explosion.Related
mechanical seal standards must be referred to take appropriate
measures such as quench,rinsing,coolong and filtrating. |
| 6. Appropricate lubrication must be choosen when mechanical seal is
installed.The installment size of the mechanical seal must be
guaranteed to the installment instruction. |
| 7. Before the machine starts running,the hermetic compartment shall
be full of medium and well lubricated.Dry friction which may lead
to the damage of the air-tightness is strict forbidden. |
